AXB-the importance of screws in hydraulic breaker

      As we know, screw is very important to machinery, the importance is not less than the key parts for machine. Because of this, Komatsu and Cater, all screws of their excavator are produced by themselves. Then let's talk about the importance of screws in hydraulic breaker.

      Firstly let's know the various strength of screws, screw grade can be classified into 4.4, 8.8, 10.9, 12.9. Each screw has its own corresponding standard. The higher grade, the higher tensile and anti-vibration. But if not using corresponding materials to make the same grade screw, the higher grade is easier to break, because its mechanical properties are not up to this standard. The screws in hydraulic breaker include penetrate screws, splint screws, accumulator screws, FM screws,etc. The following is the damaged casued by loose screws in hydraulic breaker analysed by AXB Technology Co.,Ltd.

      1. Penetrate screw: It is generally made of 12.9 alloy structural steel. Penetrate screw is an important part to fix the upper, middle and lower cylinder of the breaker. If the penetrate screw is loose or broken, it will cause piston and cylinder to be hit out of concentricity, and cylinder scraping. The penetrate screw is made of high-performance alloy structural steel, with better elongation and yield strength that carbon steel can not reach. Even in a high-strength working environment, it can still maintain high toughness and strength.

      2. Splint screw: It is generally made of 10.9 alloy structural steel. Splint screw is an important part to fix the frame and the core of breaker. If not tightened in time after loosening, the aperture and inner linng of the frame will abrase due to great stress. This kind of wear and tear will become more and more serious and finally the frame will be scrapped.

      3. Accumulator screw: As this place is special, it is generally made of materials with high temperature resistance and toughness, its strength requirement is also relatively high (all are 12.9 screws). Although the screw at the base of the accumulator is relatively small, the operation is very large. Because the weight of an accumulator is 30-40kg, and the vibration generated during operation is even greater than this power, but the fastening screws are only 4 pcs. The strength requirements of the screws can be imagined.

      Above are the importance of screws in hydraulic breaker summarized by AXB Technology. Welcome to click AXB website www.cnaxb.com to view more information.
